Packet Tracer – Configure Secure Passwords and SSH Instructor Version

Addressing Table

Re: IPSec VPN Setup in Packet Tracer 7.1 Save config, reload both router and try to ping from server. But, does not ping 192 network, from server, try to ping 10. Network on the opposite side. Jun 11, 2019 SW1 ( config)# crypto key generate rsa. How many bits in the modulus 512: 1024% Generating 1024 bit RSA keys, keys will be non-exportableOK Set the size of key to 1024 bits. If your Cisco Switch is running an older version of Cisco IOS image, then it is extremely recommended that you upgrade to latest Cisco IOS. The following is sample output from the show crypto key mypubkey rsa command. Special usage RSA keys were previously generated for this router using the crypto key generate rsa command.% Key pair was generated at: 06:07:49 UTC Jan 13 1996. Jan 15, 2020  How to Configure SSH in Cisco Packet Tracer. By Tolga Bagci January 15, 2020 Cisco Packet Tracer 0 Comments. Run Packet Tracer and then create a network topology as shown in the image below. Add an additional Router to the workspace, because after configuration we will connect the Router to the Router with SSH. #ip domain name.

Scenario

The network administrator has asked you to prepare RTA and SW1 for deployment. Before they can be connected to the network, security measures must be enabled.

Intructions

Step 1: Configure Basic Security on the Router

a. Configure IP addressing on PCA according to the Addressing Table.

b. Console into RTA from the Terminal on PCA.

c. Configure the hostname as RTA.

d. Configure IP addressing on RTA and enable the interface.

e. Encrypt all plaintext passwords.

f. Set the minimum password length to 10.

g. Set a strong secret password of your choosing.
Note: Choose a password that you will remember, or you will need to reset the activity if you are locked out of the device.

h. Disable DNS lookup.

i. Set the domain name to CCNA.com (case-sensitive for scoring in PT).

j. Create a user of your choosing with a strong encrypted password.

k. Generate 1024-bit RSA keys.

Note:free text editors for mac os In Packet Tracer, enter the crypto key generate rsa command and press Enter to continue.

l. Block anyone for three minutes who fails to log in after four attempts within a two-minute period.

m. Configure all VTY lines for SSH access and use the local user profiles for authentication.

n. Set the EXEC mode timeout to 6 minutes on the VTY lines.

o. Save the configuration to NVRAM.

p. Access the command prompt on the desktop of PCA to establish an SSH connection to RTA.

Step 2: Configure Basic Security on the Switch

Configure switch SW1 with corresponding security measures. Refer to the configuration steps on the router if you need additional assistance.

a. Click on SW1 and select the CLI tab.

b. Configure the hostname as SW1.

c. Configure IP addressing on SW1 VLAN1 and enable the interface.

d. Configure the default gateway address.

e. Disable all unused switch ports.

Note: On a switch it is a good security practice to disable unused ports. One method of doing this is to simply shut down each port with the ‘shutdown’ command. This would require accessing each port individually. There is a shortcut method for making modifications to several ports at once by using the interface range command. On SW1 all ports except FastEthernet0/1 and GigabitEthernet0/1 can be shutdown with the following command:

Cisco Switch Crypto Key Generate Rsa

The command used the port range of 2-24 for the FastEthernet ports and then a single port range of GigabitEthernet0/2.

Cisco Packet Tracer 7.2

f. Encrypt all plaintext passwords.

g. Set a strong secret password of your choosing.

h. Disable DNS lookup.

i. Set the domain name to CCNA.com (case-sensitive for scoring in PT).

j. Create a user of your choosing with a strong encrypted password.

k. Generate 1024-bit RSA keys.

l. Configure all VTY lines for SSH access and use the local user profiles for authentication.

m. Set the EXEC mode timeout to 6 minutes on all VTY lines.

n. Save the configuration to NVRAM.

Download PDF & PKA file:
